GJFJ8V Zipcored Interconnect Tight Buffer Fiber Optical Cabl

Tight Buffer Fiber Two Core GJFJ8V fiber optic cable outdoor

Product Description

Introduction

 ZCC zipcord interconnect cable is use single φ900 µm or φ600 µm flame-retardant tight buffer fibre as optical communication medium,the tight buffer fibre warpped with a layer of aramid yarn as strength member units,and the cable is completed with a PVC/LSZH jacket.

Characteristics

1. Tight buffer fiber ease of stripping

2. Good performance of flame-retardant

3. Installation: riser, plenum, etc.

4.The jacket anti-corrosing,anti-water and etc

5.Aramid yarn as strength member make cable have excellent tnsible strength

6.Figure 8 structure jacket facilitate embranchment.

7.All dielectric structure protect it from electromagnetic influence.

Standards:

Comply with standard YD/T 1258.3-2003, ICEA-596, GR-409, IEC 60794-2-10/11, etc; and meet the requirements of UL approval for OFNR and OFNP.

Application:

1.duplex optical fibre jumpter or pigtail

2.indoor riser level and plenum level cable distribution

3.interconnect between instruments,communication equipments




Parameter

Cable code	Cable Size mm	Cable weight Kg/km		TBF diameter       um	Tensilse Strength  Long/Short term     N	Crush Resistance  Long/Short term  N
GJFJ8V	(6.0±0.4) ×(2.8±0.2)	PVC jacket	LSZH jacket
		11.6	14.8	900±50	100/200	200/1000
